Large Tracked Loader NC10004 with 1,000 kg Payload

NC10004 Tracked Shovel Carrier

The Onchtech NC10004 is a tracked shovel carrier that integrates material scooping, short‑distance transport, and multi‑angle dumping into a single machine, suitable for construction work, agricultural operations, landscaping, mountain transport, and unpaved road applications. Featuring a compact tracked undercarriage, the unit can handle sand, earth, branches, agricultural supplies, and on‑site debris on muddy, gravel, sloping, and narrow‑passage terrain.

Complex Terrain Accessibility and Confined‑Space Operation

The NC10004 features a tracked running system and independent suspension, enhancing ground contact and travel stability on soft, muddy, uneven, and unpaved surfaces. With a compact width of approximately 850 mm, the machine can easily access field paths, orchard trails, building perimeters, garden routes, and work zones where large equipment cannot reach.

Scooping, Transport, and Multi‑Angle Dumping

The unit is equipped with a self‑loading bucket that can collect materials within a certain range, integrating loading, transport, and dumping functions into a single machine. The hopper supports rotation and multi‑angle side dumping, allowing flexible adjustment of material discharge direction according to passage orientation, unloading positions, and on‑site obstacles.

Power, Construction, and Control Configuration

The NC10004 is powered by a 15 HP, 500 CC gasoline engine paired with a 10 cc/r hydraulic gear pump, delivering power for travel, scooping, and dumping through the combined engine‑hydraulic system. The cargo bed is manufactured from high‑strength wear‑resistant steel plate with a minimum yield strength of 800 MPa, capable of withstanding impact and abrasion from sand, earth, and other common materials.

• Hydraulic Power System: Suitable for continuous short‑haul transport as well as combined scooping, travel, and dumping operations.
• High‑Strength Cargo Bed: Enhances wear and impact resistance under high‑frequency loading/unloading and handling of construction materials.
• Operation & Management: Supports electronic control levers, multiple control modes, intelligent fault diagnostics, and remote monitoring functions.

Typical Application Scenarios

The NC10004 is primarily designed for short‑distance, multi‑point material handling under complex road conditions, serving as a compact tracked material handling unit and on‑site auxiliary transport solution.

Selection and Customisation Support

For construction contractors, agricultural operators, landscaping service providers, equipment dealers, and construction machinery integrators, the NC10004 can be selected as a tracked shovel carrier for complex terrain and confined spaces. Prior to purchase, it is recommended to evaluate the material type, road conditions, passage width, dumping direction, operation frequency, and local usage requirements.

Onchtech can provide complete machine delivery as well as OEM, ODM, and OBM cooperation support based on different market working conditions and configuration needs, including structural adaptation, control configuration, and regional product solution discussions.
